T-Motor AS2814 2000KV

The AS2814 KV2000 is the “speedster” of the AS series. While other motors focus on large-prop torque, the 2000KV variant is built for high-RPM efficiency, making it the ideal choice for smaller, high-pitch propellers on 2S to 3S LiPo setups.

Part of T-Motor’s value-oriented AS line, this motor doesn’t cut corners. It utilizes Japanese bearings and curved (arc) magnets to reduce the air gap, resulting in higher efficiency and a “locked-in” feel during demanding maneuvers like rolling harriers or knife-edge loops.

Key Performance Advantages:

• Long Shaft Design: Specifically designed for easy mounting in streamlined 3D and F3A fuselages, ensuring perfect propeller alignment.

• High-Speed KV: The 2000KV rating provides the high RPM needed for 20-30E class models to perform vertical climbs and high-speed passes with ease.

• Robust Build: Constructed with a high-strength metal casing and heat-resistant windings to ensure the motor survives the rigors of competitive flying.

• Smooth Operation: Quality Japanese bearings minimize vibration, protecting your airframe and ensuring a quiet, efficient flight.

Technical Specifications:

• Model: AS2814 (Long Shaft)

• KV: 2000

• Configuration: 12N14P⁹

• Dimensions: Φ36.2 × 54.5 mm

• Weight: 116g (including wires)

• Recommended Battery: 2S – 3S LiPo

• Internal Resistance: $23m\Omega$

• Idle Current (10V): 2.2A

Recommended Setup:

• Airplane Class: 20-30E 3D / F3A Fixed Wing

• ESC: T-Motor Fixed Wing AT Series (40A – 60A)

• Propellers: 8″ to 10″ High-Efficiency Props (depending on battery cell count)
