Take your flight experience to the next level with the DAKEFPV H743 Stack. At its core sits the STM32H743 processor, which operates at significantly higher speeds than standard F7 chips, allowing you to run complex filters and high-frequency PID loops with ease.
This stack is paired with a 60A 4-in-1 ESC designed for the modern high-voltage era. Rated for up to 8S LiPo, it features high-quality MOSFETs and a massive heat sink to maintain performance during aggressive punch-outs. Whether you are building a cinematic long-range cruiser or an 8S “speed demon,” the DAKEFPV H743 provides the stability and power you need.
Key Performance Highlights:
-
H7 Powerhouse: The STM32H743 MCU provides unparalleled processing power, making it perfect for advanced users running ArduPilot or complex Betaflight configurations.
-
Dual Gyro Precision: Equipped with dual IMU options (ICM42688/MPU6000) to ensure crystal-clear flight data and vibration resistance.
-
8S LiPo Ready: Built to handle the voltage of high-performance builds, supported by high-quality MOSFETs and built-in TVS diode protection to prevent voltage spikes.
-
Ultimate Connectivity: With over 7 UARTs, you can simultaneously connect a DJI O3 Air Unit, GPS, Compass, VTX, and Telemetry without running out of ports.
-
Universal Mounting: Features a dual-mounting design (20x20mm and 30.5×30.5mm), making it compatible with almost any modern FPV frame.
Technical Specifications:
-
FC MCU: STM32H743VGT6
-
Gyro: Dual ICM42688 / MPU6000
-
ESC Current: 60A Continuous | 70A Burst
-
Input Voltage: 3S – 8S LiPo (FC supports up to 12S)
-
Firmware: Betaflight, ArduPilot, iNav
-
ESC Firmware: BLHeli_32 / AM32
-
OSD: AT7456E (Analog) & HD OSD (Digital)
-
UARTs: 7+ Hardware UARTS
-
Mounting: 30.5×30.5mm & 20x20mm
